Refer to Health and Safety section before carrying
out any service work.
Note: Drain compressor oil prior to servicing the following item.
Refill with oil after service completion.
Thermal By-pass valve
If necessary check the thermostat (14) for correct operation.
Thermostat starts operation at 82
°
C and normal extension at 96
°
C
is 9.5 mm (14.3 mm max.).
•
Clean and degrease all parts. Ensure piston (13) is free from
score marks and sharp edges.
•
If new thermostat is to be fitted, DO NOT REMOVE STEM.
•
Renew bonded seal (16).
Page 36
CompAir Hydrovane
2F Oil Chamber Arrangement
Item Part Number Description Kit
Quantity
All 705 707
34398 Oil chamber assembly 1
1 71495 Oil chamber 1
2 0782 Bearing 1
3 59425-03 Taper plug brass 3/8 BSP 2
4 9613 Bonded seal KM71 3
5 57996 Drain plug 3/8 BSP 2
6 59425-01 Taper plug brass 1/8 BSP 2
7 57798 Oil return plug assembly 1
8 58306 Delivery pipe 16mm 1
9 58340 Lock-nut 16mm 1
11 MHC6-15 M6 x 2.5D Helicoil 2
12 52487 Spring 1
30661 Thermal bypass piston assembly 1
13 52486 Piston 1
14 3515C Thermal motor 1
15 MCI-22 Circlip 22mm internal 1
16 9624 Bonded seal KT71 1
17 53191 End cap 1
18 MS706-20 Socket head screw M6 x 20 2
19 59046 Filter cap 1
20 9763 O Ring KM71
1
