CompAir Classic 05 - Page 34

Refer to Health and Safety section before carrying
out any service work.
3. Deflector and Oil Relief Valve
Deflector
•
Ensure that the port on the deflector (10) is facing the intake end
of the stator (13) on assembly.
Oil Relief Valve
•
Remove screw (17) and washer (18) from the oil relief valve.
•
Remove support (19) and plate (20).
•
Check plate (20) for wear or damage. Renew if necessary.
•
Ensure valve seating surface on stator is perfectly flat. Use an
emery stone to obtain flatness.
•
Remove all traces of emery dust.
•
Renew washer (18) on screw (17).
•
Renew screw (17) if worn.
•
Check valve guide pins (16). Renew if worn or bent.
Page 34
CompAir Hydrovane
2E Rotor Stator Unit - Dismantling
Item Part Number Description
Quantity
All 705 707
7
Bar
10
Bar
7
Bar
10
Bar
15c 58018-04 Gasket 0.08mm A/R 1 1 1
15d 59302-03 Gasket 0.05mm A/R 1
15e 59302-04 Gasket 0.08mm A/R 1
16 57027 Tension pin 2
17 FS702-3 Screw 4BA x 3/8 1
18 AGS203-B Spring washer 1
19 56586 Valve support 1
20 56302 Valve support 1
21 57802 Key 1
22a 59187-01 Blade 12 12
22b 59187-02 Blade 12 12
23a 58186 Rotor 1 1
23b 58038 Rotor 1 1
24 58691 Clip 1
25 58411 Impingement cowl 1
