Refer to Health and Safety section before carrying
out any service work.
Page 68
CompAir Hydrovane
3A 01/02 Three Phase (PUTS) Starter
Item Part Number Description Kit
Quantity
Starter Assembly No.
34367
1 74097 Contactor 3
2 74035 Thermal overload 1
3 74022 Terminal 5
4 74023 Earth terminal 1
5 74024 Terminal, double stack 12
6 74036 Transformer 1
7 56132 Fuse 1A 1
8 74027 Fuse 1.6A 2
9 74038 Emergency stop button 1
10 74028 End bracket 2
11 74043 Power outlet socket 1
12 74039 Aux. contact block 2
13 74064 Circuit breaker 1
14 74063 Aux. contact block 1
15 74025 End section 2
Starter assembly 34367 = 5.5/7.5 kW, 400 Volt, 50 Hz Electronic Control
