Refer to Health and Safety section before carrying
out any service work.
Page 76
CompAir Hydrovane
3E 400V 50Hz and 380/440V 60Hz Standard Control Starter
Item Part Number Description Kit
Quantity
Starter Assembly No.
34409
1 74029 Contactor 110V 60Hz 1
2 74024 Terminal, double stack 3
3 74025 End section 2
4 74026 Transformer 1
5 56132 Fuse 1A 2
6 59344 OTC board 1
7 56122 Timer 1
8 53494 Timer base 1
9 74067 Knob operator (Auto) 1
10 74068 Indicator lamp (Reset) 1
11 72708 Push button (Start) 1
12 74080 Hours counter 1
13 72706 Emergency stop push button 1
14 74043 Power outlet socket 1
15 74039 Auxilary contact block 1
16 74064 Circuit breaker Q1F 1
17 74022 Terminal 3
18 74023 Earth terminal 1
19 74020 Thermal overload 5.5/6.5kW (460V) 1
20 74021 Thermal overload 5.5kW (208-230V) 1
21 74030 Thermal overload (208-230V) 1
22 74079 Connector thermal overload 1
Starter assembly 34409 = 5.5/7.5 kW, Nema 60 Hz D.O.L. Standard Control
