JHT01 Service Manual
2-24
CMD DATA Description return
B7h Modem ring enable None
B8h Modem ring disable None
B9h PME enable None
BAh PME disable None
BBh In S4 status None
BCh Resume form S4 status None
BDh RTC wake up enable None
BEh RTC wake up disable None
C1h Force battery pack auto learning (Support in
battery learn mode)
None
C2h Disable battery pack learning (Support in battery
learn mode)
None
C3h SMI/SCI Trigger event enable None
C4h SMI/SCI Trigger event disable None
CBh PCMCIA suspend disable None
CCh PCMCIA suspend enable None
CDh Wake up LAN disable None
CEh Wake up LAN enable None
D0h Disable IRQ1 None
D1h Enable IRQ1 None
D2h Beep alarm 200mS None
D5h PCMCIA reset on None
D6h PCMCIA reset off None
D7h Battery stop charge enable None
D8h Battery stop charge disable None
D9h Set system flag None
DAh Clear system flag None
E1h Turn LCD back-light on None
E2h Turn LCD back-light off None
E4h Select EX keyboard Matrix None
E5h Select US keyboard Matrix None
E6h Select JP keyboard Matrix None
E7h Select UK keyboard Matrix None
E8h EC into ACPI mode None
E9h Non-ACPI mode (EC default) None
F1h Enter Idle mode None
F2h Enter flash mode None
F6h To get the System action flag None
F7h Restart system and Clear header of Boot code None
F8h Shut down system and Clear header of Boot code None
F9h Clear header of Boot code None
5Ah RTC update (No Support)
A0h Update Year of RTC, Year (00-99) BCD format
Year which want to display None
A1h Update Month of RTC, Month (1. 12) BCD format
Month which want to display None
A2h Update DAY of RTC, Day (01-07) BCD format
Day which want to display None
A3h Update HOUR of RTC, Hour (00-23) BCD format
Hour which want to display None
A4h Update Minute of RTC, Minute (0. 59), BCD
format
