Fault description
number
Fault description
9 High level shutdown trip
8 High level alarm
7 High level start inhibit
6 Special function
5 Sensor error
4 Timeout
3 Low level start inhibit
2 Low level alarm
1 Low level shutdown trip
0 Digital input
Input number Input
# Input number for controller input terminal/location
Input location
number
Input location description
0 Digital input
1 Analogue input
2 to 7 Not used
8 Special functions
9 Special functions slave unit
Fault Category
Number
Fault category description
0 Immediate shutdown trip error
1 Controlled shutdown trip error
2 Alarm
3 Start or run inhibit
4 Service
Fault type Fault type description
E Shutdown trip error
A Alarm (or service message alarm)
S Start inhibit
R Run inhibit
