5.5
Replacing air lter
The air lter (1) is attached to the com-
pressor’s intake valve.
In order to replace it, open the front side
panel, loosen the clamp (2) securing the
lter. Remove the contaminated lter, and
detach the clamp from it.
Set the new lter in its place and t into
place with the clamp.
Fig. 5.5 Air lter replacing
5.6
Changing drive belt
Fig. 5.6 Changing drive belt
Open the front and right side panel, loosen the 4 screws (3) securing the bracket of the air
end by turning them 2 revolutions. Loosen the 2 bolts of the support (2) and the 2 corre-
sponding nuts (1) on the tensioner using a wrench. Remove the old belts from the pulleys
and install the new belts. After installing the new belt, tighten the belt with the appropriate
tensile force (see section 5.3 Checking Drive Belt). Tighten the 2 bolts of the support (2)
2
1
2
