Fig. 5.2 Checking oil level
5.3 Checking drive belt
Check on a daily basis drive belts condition and the tension on drive belts.
In order to access the belt, stop the
com-pressor and remove the right side
panel. Inspect belts (1) for signs of
wear on side edges and for cracks.
If belts are damaged, then they
should
be replaced
1
1
Fig. 5.3 Cheking drive belt.
