Operation l 4-7
4
Operation
Screen
SCREEN 10 (Setback
Temperature Option)
SCREEN 11 (Setback Options)
Function
Control Function Descriptions
(continued)
If the dryer has the setback on temperature
option installed, this is the temperature
setpoint for the air at the outlet of the dry-
ing hopper. When this setpoint is reached,
the dryer will automatically change the
process setpoint to the setpoint shown on
Menu number 7, Screen 11. When the
temperature at the outlet of the hopper
drops below the setpoint (entered on this
screen, in this example 150) by the value
shown under C09, Screen 23, the dryer
will return to the normal drying setpoint.
If the dryer has the setback on temperature
option installed, this is the temperature set-
point to which the process air will revert
once the air at the outlet of the hopper has
reached its setpoint (Screen 10, Menu
number 6).
150
120
6
145
250
7
When supplied for
central drying applica-
tions, these functions
are not available.
NOTE: See informa-
tion on page 4-24 for
use of Setback.
✐
