Conair 200 - Page 44

4-8 l Operation
Screen
SCREEN 13 (Dewpoint
Monitor/Dewpoint Control Option)
SCREEN 14
Screens 15-27 require access
code 754.
SCREEN 15 (Set up Screen)
Function
Control Function Descriptions
(continued)
If the dryer has the dewpoint monitor
option installed, this screen will show the
actual dewpoint of the process delivery air
measured after the desiccant wheel in the
process position but before the process
heater. With the dewpoint monitor option
installed, there will only be an actual dis-
play (no setpoint value). Although the
dryer is capable of producing dewpoints
much lower than -40
°F {-40
°C}, the mini-
mum sensor range is -40
°F {-40°C}
. dew-
point control will automatically adjust the
regeneration temperature to maintain dew-
point setpoint. Dewpoint control is not
active with -40
°F {-40°C} setpoint.
This is the password entry screen that
gives the user access to the Set Up, Test
Mode, and Alarm History screens. The
user can get to the non-password protected
control functions through this screen by
pressing the scroll button and the adjust
setpoint button at the same time. This
works only if you are on menu #1 (default
screen). The access codes are as follows:
Set Up Screens 754
Test Mode Screens 755
Alarm History Screens 756
To exit the password section, enter 500 and
press scroll or cycle the power.
This is the process deviation temperature
screen. The range is 5 to 20
°F {3 to
11°C}. This is the deviation temperature
band around the set point. If the dryer
goes outside this band, the dryer will
display a passive alarm (P1).
-30
-40
8
0
0
10
C01
C
When supplied for
central drying appli-
cations, this function
is not available.
