Screen
Screens 18-24 require access
code 754.
SCREEN 22 (Set up Screen)
Regeneration Air Temperature
SCREEN 24 Aftercooler/
Intercooler Flow Control Enable
(Option)
Screen 28-43 require access
code 755.
SCREEN 28 (Test Mode Screen)
Function
Control Function Descriptions
(continued)
This screen shows the actual temperature
of the regeneration air at the outlet of the
desiccant wheel.
This screen is the Aftercooler/Intercooler
Flow Control Enable screen. By pressing
the (+) or (-) keys, this function can be
turned on or off. When off, the dryer will
not open the optional flow control valve to
control the return air temperature. There
will also be no setpoint value on Menu #3,
Screen 7. This screen is not visible if the
aftercooler/intercooler flow control option
is not installed on the dryer.
This is the Test Mode screen for the
process blower. By pressing the (+) or (-)
keys, the setting can be changed. When
set to "On", the process blower output will
be turned on for 3 seconds and then shut
off automatically.
(continued)
✐
off
C10
C
off
1
H
200
C08
C
✐
To Next Page
