Maintenance l 5-7
5
Maintenance
Cleaning the Process Filter (continued)
3 Remove the filter wing nut, then
remove the filter.
4 Remove outer filter and clean it with soapy
water. Let air dry.
5 Clean the filter by laying it on its side and gently tapping it on the floor. Replace
damaged, worn, or clogged filters.
6 Reverse the procedure to reinstall the process filter. Ensure that the gasket on filter cap is
in place and in good condition.
CAUTION: Wear eye protection. If you use compressed air to clean the equipment, you must
wear eye protection and observe all OSHA and other safety regulations pertaining to the use of
compressed air.
TIP: If gasket on the process filter cap becomes loose or detached from the filter cap, resecure with high
temperature silicone adhesive.
✒
Carousel Plus W-series Dryers 600-5000
NOTE: On models W1600-5000 the process filter
will not have an outer filter.
✐
