6
Troubleshooting
Troubleshoot ing l 6-29
Replacing the Regeneration Heater
(W1600 - 2400) (continued)
8 Slide the original insulation over the new heater, or if the insulation was cut
for removal, wrap the cut insulation sleeve around the new heater tube and
secure it with heat tape.
9 Make sure the cable end of the new heater tube is to the bottom, then
connect the hoses to the top and bottom of the heater tube and resecure
with pressure clamps and the lower heater tube bracket that was removed in
Step 5.
10 Connect the high temperature switch cable to the quick disconnect.
11 Route the heater power wires into the junction box, and connect them to
the supply leads from the control box. Refer to the wiring diagram for spe-
cific connection information.
12 To ensure all connections are correct, measure the resistance as in Step 3.
You should measure the readings as noted for a good heater.
13 Close the side panel of the dryer.
14 Connect the dryer to power and turn it on. Verify the regeneration temper-
ature achieves the setpoint.
