SRT X-BAND RADAR SYSTEMS
ANNEX
304202P003 3 Rev. C
Main Shield and inner shields handling
• Remove the metallic film from each twisted pair cables and pass the 4
ground wires through the turned shield.
0.35 mm² cores
• Cut the core to the wanted length and dismantle the core for 10mm:
• Insert and crimp the blue-end terminal:
Note: End terminal should always be used.
• Double connection in one terminal (yellow terminal):
To Next Page
