2. Specifications
PC-686BX(NLX)-LV, PC-686BX(NLX)-LVV
5
2.
Specifications
Functional Specifications
Table 2.1. Functional Specifications < 1 / 2 >
Processor socket Socket370
Intel Celeron 300 to 850MHz
Pentium III 500 to 850MHz (FSB100MHz)
Bus speed 66 MHz/100 MHz
Celeron CPU contains internal 128KB L2 cache
Pentium III CPU contains internal 256KB L2 cache
Memory (Option) Max. 512MB 168-pin DIMM socket x 2 SDRAM PC100
Chipset Intel 440BX
C&T 69030 controller (PC-686BX(NLX)-LVV)
C&T 69000 controller (PC-686BX(NLX)-LV)
CRT connector: VGA compatible HD-SUB 15-pin
CMOS data backed up by Lithium battery (CR2032)
The following table lists the Lithium battery specifications (button-type)
Specification CR2032
Voltage 3V
Capacity 220mAh
Weight 3.1g
The battery backup term of CR2032 is 3.0 years or more.(In main power is off.)
Award BIOS, includes Plug&Play (PnP)
512KB flash EEPROM
Power management: Uses ACPI
CPU frequency/voltage control (Not modifiable)
PS/2 keyboard
PS/2 mouse
1 x 5-pin expansion keyboard connector
2 x 16550 compatible UARTs
COM1 : RS-232C
(Includes 10-pin header connector -> D-SUB 9-pin (male) conversion cable)
COM2 : RS-232C/422/485
(Includes 10-pin header connector -> D-SUB 9-pin (male) conversion cable)
Parallel port 1 x SPP, ECP, EPP high speed parallel port
(Includes 26-pin header connector -> D-SUB 25-pin cable)
IDE interface 2 x EIDE ports, Max. 4 x IDE devices UltraDMA/33 connected to NLX BUS
FDD interface Supports 2 x drives (360K/720K/1.2M/1.44M/2.88M/LS-120), Connected to NLX BUS
SSD socket Supports M-Systems DiskOnChip 2 - 144MB
CPU (Option)
Cache
VGA
BIOS
Keyboard/mouse
connector
Serial ports
Realtime clock
/calendar
Item Specification
Please change the CR2032 battery when it goes
down under 2.3V.
If you don't change it, when booting system, CMOS
Checksum Error occurs and OS doesn't boot, and
when Power off, RTC maybe stopped.
To Next Page
