5. CPU Board Resources

PC-686BX(NLX)-LV, PC-686BX(NLX)-LVV

Memory Map

Table 5.2. Memory Map

Address Range (h) Size Description

100000-18000000 512MB Expanded memory

E8000-FFFFF 96KB System BIOS

E0000-E7FFF 32KB System BIOS (Can be used for UMB)

C8000-DFFFF 96KB

Available DOS high memory

(Available to ISA bus and PCI bus)

A0000-C7FFF 160KB Video memory and BIOS

00000-9FFFF 640KB Original memory

DMA Channels

Table 5.3. DMA Channels

DMA

0 8 or 16 bit Reserved

1 8 or 16 bit Reserved (or parallel port (for ECP))

2 8 or 16 bit Diskette driver

3 8 or 16 bit Reserved (or parallel port (for ECP))

4 --- Unused (Cascade channel)

5 16 bit Free

6 16 bit Free

7 16 bit Free

System ResourceData Size
