2. Specifications
6
PC-686BX(NLX)-LV, PC-686BX(NLX)-LVV
Table 2.1. Functional Specifications < 2 / 2 >
Intel 82559
1 x RJ-45 connector
Wake On LAN support (Only when ATX power supply used)
USB interface Supports 2 x USB ports pin header 10-pin (USB connector cable sold separately)
Timeout settings :
Selectable 0, 2, 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, or 30 seconds
Generates reset or NMI on timeout
DMA Chipset includes 2 x 82C37 equivalent, 7 channels
Interrupts Chipset includes 2 x 82C59 equivalent, 15 levels
Expansion bus NLX BUS
Super I/O Winbond W83977TF
Monitoring IC Winbond W83781D
Watchdog
LAN interface
Item Specification
General Specifications
Table 2.2. General Specifications
Current consumption
(For Celeron 733MHz )
+5VDC 10A
+12VDC 200mA
+5VSB (standby) 300mA
(For Pentium III 850MHz )
+5VDC 12A
+12VDC 200mA
+5VSB (standby) 300mA
Ambient temperature (storage) -40 to +80°C
Ambient temperature (operation) 0 to +60°C
Ambient humidity 20 to 80%RH (No condensation)
Suspended particles Not especially severe
Corrosive gases None
DC voltage : +5V (+4.75 - +5.25V)
DC voltage : +12V (+11.4 - +12.6V)
External dimensions (mm) 122(L)×220(W)
Weight 380g
SpecificationItem
System power supply
requirements
