7. BIOS Setup
PC-686BX(NLX)-LV, PC-686BX(NLX)-LVV
69
Integrated Peripherals
RxD , TxD Active : Hi,Hi
IR Transmission delay : Disabled
Onboard Parallel Port : Disabled
Parallel Port Mode : SPP
ECP Mode Use DMA : 1
EPP Mode Select : EPP1.9
IDE HDD Block Mode : Disabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO : Auto
IDE Secondary Slave PIO : Auto
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA : Auto
On-Chip Primary PCI IDE : Enabled
On-Chip Secondary PCI IDE : Enabled
USB Keyboard Support : Disabled
Init Display First : PCI Slot
KBC input clock : 6 MHz
Onboard FDC Controller : Disabled
Onboard Serial Port 1 : Disabled
Onboard Serial Port 2 : Disabled
UART Mode Select : IrDA
UART2 Duplex Mode : Full
ESC : Quit : Select Item
F1 : Help PU/PD/+/- : Modify
F5 : Old Values (Shift)F2 : Color
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
ROM PCI/ISA BIOS
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
IDE HDD Block Mode
This setting enables the hard disk controller to use high speed block mode when
performing data transfer with a hard disk drive (HDD).
Selection options: Enabled, Disabled
IDE Primary/Secondary Master/Slave PIO
The four IDE PIO (program I/O) fields set the PIO mode (0-4) for each of the four IDE
devices supported by the on-board IDE interface. Performance increases
progressively from mode 0 to mode 4. In automatic mode, the system automatically
selects the optimum mode for each device.
Selection options: Auto, Mode 0, Mode 1, Mode 2, Mode 3, Mode 4
To Next Page
