Genus G1 MARK II Users Manual
UM3010-2
Installation
The installation process proceeds with the bulleted items below. All installation steps are
discussed in the Installation Guide for Genus G1 MARK II (IG3010-2) Terminal. However,
follow only those that apply to your installation requirements.
• Wall Mount Installation & Recommended Height
• Grounding the G1 Terminal
• Wand / Scanner and Ethernet Connections
• Serial Aux Port Connection
• Digital Input Connection
• Digital Output Connection
• Power and UPS Connections
• Modules
• WiFi Antenna
• WiFi Module Connections
• Modem Module Connections
• Close & lock the Terminal and Store the Key
Servicing
Do not attempt to repair this product yourself. Opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all servicing and installation to qualified
personnel. (Refer to the Service & Technical Support section at the back of this document).
