Genus G1 MARK II Users Manual
UM3010-2
Indicator LED Troubleshooting Table
If the... Perform These Tasks...
Power LED does not turn
On.
Check power connector is properly inserted. Contact your service
technician.
Power LED turns Red. Remove power and re-apply. If the Power LED remains Red,
contact CMI.
Power LED is Amber. WiFi Module has not established an IP address either through
DHCP or Static methods.
If DHCP is enabled, your network must have a DHCP server
available when the WiFi Module is powered-up. Most AP/Routers
have a DHCP server built-in.
Enable your DHCP server and re-start the Module.
Link LED continues to Blink
Red.
WiFi Module has not found an Access Point with which to
associate. Be sure the Access Point you want to use is turned on
and has WEP disabled (you can enable WEP after the WiFi
Module has been configured).
If this does not help, be sure there are no nearby devices causing
interference. If there are, either turn off or move the device
causing the interference or move the WiFi Module and Access
Point to another location.
Comm LED is Off or Amber. Be sure the Genus terminal is connected to the WiFi Module and
that the device is turned on.
Comm LED is Red and Link
LED is Green but you are
unable to pass data.
Check the Ethernet settings of the Genus terminal. Except for the
last octet of the IP address, all settings should match those of the
WiFi Module. If the Terminal is set for DHCP, your network must
have a DHCP server available when the Genus Terminal is
powered-up.
Revision B 10-30-07 58
