Genus G1 MARK II Users Manual
UM3010-2
WiFi LED Description
LED LED
Color
Function
Off No power, or no WiFi configuration session is
established and no Ethernet physical connection is
detected.
Red No WiFi configuration session is established; an
Ethernet physical connection is detected.
Blinking
Red
An Ethernet physical connection was detected and there
is Ethernet traffic present on that connection, but no WiFi
configuration session is established.
Comm Amber A WiFi configuration session is established but no
physical Ethernet connection is detected (i.e., no
Ethernet cable is attached to the Module).
Blinking
Amber
A WiFi configuration session is established, a physical
Ethernet connection is detected, and the Module is
transmitting or receiving data across the wired Ethernet
port.
Green A WiFi configuration session is established, a physical
Ethernet connection is detected, but there is no active
data movement across the wired Ethernet port.
Off Module is not receiving power.
Link Blinking
Red
Module is searching for an Access Point.
Green Wireless network and MAC have associated with an
Access Point.
Off Module is not receiving power.
Power Red Module failed its Power On Self Test (POST) and is not
configured for wireless communication.
Amber Module passed its POST but is not configured for
wireless communication.
Green Module passed its POST and is configured for wireless
communication.
Revision B 10-30-07 59
