CONVAID USER’S GUIDE
Rodeo without Upholstery Seating Overview
Fig. 2
Serial Number Label
Chair Warning Label
290 mm x 60 mm
Rear Solid Wheels
Recline Release Strap
One Piece Height Adjustable Push Handle
Tilt Adjustment Lever
190 mm x 51 mm
Front Solid Wheels
One Piece Angle Adjustable Footplate
Depth Adjustable Solid
Seat Pan (Option)
Packaging Label
(reference)
Back Canes
Never leave occupant unattended. Failure
to read and follow user guide instructions
could result in serious injury. To obtain a
replacement user’s guide email sales.us@
convaid.com or call 844-876-6245.
