11
CONVAID USER’S GUIDE
Setting Up
Rodeo with Seating Overview
Fig. 5 Locking Fig. 6 Unlocking
Wheel Lock Operation
1. Lock the wheels by pushing the wheel lock bar downward. Fig. 5
2. Disengage the wheel lock by pulling the wheel lock bar upwards with the top of your foot. Fig. 6
DOWN UP
1. Press both gray buttons on the outside of the pivot joints of the push handle simultaneously. Fig. 3
2. While holding the buttons down, move the push handle up or down to the desired position. Fig. 4
3. Release the gray buttons on the push handle.
Fig. 3 Fig. 4
CAUTION: Improper use may cause premature brake failure, which could damage wheel lock.
Never use excessive force. This could damage the quick release plunger pins and the wheels
could fall off and cause injury.
