CONVAID USER’S GUIDE
Wheels
Specications
The Rodeo comes standard with 190 mm x 51 mm front and 290 mm x 60 mm rear solid tires. When
ordering replacements or pneumatic wheels, please have the
following information available:
• Chair model and size
• Wheel size
Pneumatic Tire Sizes
Dimensions
190 mm x 51 mm
front
Dimensions
290 mm x 60 mm
rear
Rear Tire Removal
Rear Wheel Locking Pin
Fig. 85 Fig. 86
Grasp wheel, press down and hold the
rear wheel locking pin and pull wheel
out of rear axle.
NOTE: No tools are required
to remove tire.
CAUTION: Do not use the chair unless it has proper tire pressure. (Front 36 psi/Rear 30
psi, 248kPa/200kPa, 2.5BAR/2.0BAR) Do not overinate the tires. Failure to follow these
instructions may cause the tire to explode and cause harm. Tire size and maximum pressure
as listed on the wheels.
