Convaid Rodeo - Recline Function; Upright Position; Recline the seat back

18
CONVAID USER’S GUIDE
HELPFUL HINT:
For ease of use, lift the push handle upwards during the entire
recline process.
Upright Position
Step: 1
Rotate Push Handle upward:
Push-in the Gray Push Buttons located on the side of the push
handle, at the same time, rotate the Push Handle upward.
Fig. 51 & 52
Step: 2
Recline the seat back:
Lift Push Handle upward Fig. 53 to relieve the occupant’s weight.
At the same time, pull upwards on the Recline Strap Fig. 54, and
recline the seat back to desired position Fig. 55.
Upright Position
To return seat back to upright position repeat steps 1 & 2. Hold top
of seatback and push back up to bring upright, instead of reclining.
Recline Function
Fig. 51 Gray Push Button
Fig. 52 Rotate Push Button
upward
Fig. 53 Lift Push Handle
Upwards
Fig. 54 Pull forward on Recline
Strap
Fig. 55 Recline the seat back
