CONVAID USER’S GUIDE
Fabric Removal
Chair upholstery may be removed to facilitate cleaning.
Removing seat upholstery and under seat mesh support: Fig. 56-59
1. Remove screws at the front of seat tube.
2. Unfasten the Velcro
®
on the seat upholstery and the under seat
mesh support located at the back of the seat.
3. Pull seat upholstery towards leg rest extensions.
4. Release Velcro
®
from calf support to remove seat upholstery from
the chair.
Removing back upholstery: Fig. 60-62
1. Unscrew top straps located below the push handle.
2. Release the Velcro
®
Straps on the back side of the chair.
3. Release Velcro
®
pelvic stabilizer straps and pull upholstery away.
NOTE: Do not replace upholstery until it is completely dry.
Fig. 56
Fig. 57
Fig. 58
Fig. 61
Fig. 59
Fig. 62Fig. 60
To adjust upholstery for individual footplates:
1. Lay Rodeo on its side for easy access to area beneath seat
2. Undo all three Velcro
®
straps beneath seat.
3. With upholstery extended, wrap upholstery underneath seat and refasten Velcro
®
straps.
