Convaid Rodeo - Caster Locks; Utility Bag; Shoe Holders

35
CONVAID USER’S GUIDE
Shoe Holders
1. Thread the 3-bar slide onto the strap with the curved side down. Feed the strap through the
molded strap slot. If you have the padded version, thread the pad onto the strap as shown
Fig. 128
2. Thread the strap end through the buckle. Fig. 129
3. Thread the strap end through the 3-bar slide. Fig. 130
Fig. 128 Fig. 129 Fig. 130
Fig. 127
Utility Bag
The Utility Bag is for storing essential items. It attaches to the
back of the chair, and can be removed and converted to a tote
bag. To attach bag to chair, hook clasps into rings located on the
backside of chair. Fig. 127
Caster Locks
Fig. 126
Push down
to engage
Caster Lock
Push here to
disengage
Caster Lock
1. Engage caster lock by pushing the caster lock down.
Fig. 126
2. To disengage the caster lock, push the bottom portion of
caster lock. Fig. 126
