CONVAID USER’S GUIDE
Providing Clear Space & Padding
Position the wheelchair aboard the motor vehicle to ensure sufcient clear space in front of, and
behind, the occupant. Fig. 151 & 152
RECOMMENDED CLEAR ZONES IN VEHICLE
The rear clear zone is measured from the rearmost point on an occupant’s head. The front clear zone
is measured from the frontmost point on an occupant’s head.
Dimensions are shown in millimeters.
Fig. 151 Fig. 152
CAUTION: If there are any hard or sharp objects or components near the wheelchair,
such as components of lifts or fold-up seats, they must be covered with heavy-duty
energy-absorbing padding to ensure the safety of the wheelchair occupant and other
passengers.
