Optional Attendant Hand Brake
Hand brakes help to maintain control of the chair when going
down an incline. A moderate squeeze to the lever will slow the
chair; a rm squeeze will stop the chair. Fig. 131
Attendant Hand Brake - Tire Installation:
Slide wheel onto rear axle, and push on wheel until it clicks into place. Fig. 132 - 134
IMPORTANT: Before pushing on wheel, make sure the brake band is ush with the inside of the brake
housing.
Tilt Brake
Fig. 131
Fig. 132
Fig. 133
Fig. 134
CAUTION: Always make sure the wheels are installed properly. You will hear a“click” when the
wheel lock into place.
