Appendix B. Configuration Tables ALSPA PROFIBUS Field Bus Coupler
Page B4 Technical Manual (09/06)
Table B-7 Programmable Status Word 1
Bit
Param.
No.
Control
Flag No.
Description
Example
0 P41.16 2.001 Bit 0 mapped to Stopped flag
0 P41.16
1 P41.17
2 P41.18
3 P41.19
4 P41.20
5 P41.21
6 P41.22
7 P41.23
8 P41.24
9 P41.25
10 P41.26
11 P41.27
12 P41.28
13 P41.29
14 P41.30
15 P41.31
Table B-8 Menu 42 - Reference Pointers
No. Param. Points
To
Param.
Scale Function
Example
1 P42.00 74.12 10000 Speed Reference
1 P42.00 Speed Reference
2 P42.02 Speed Reference
3 P42.04 Reference Sequencer
4 P42.06 PID Set-point
5 P42.08 PID Feedback
6 P42.10 Trim Reference
7 P42.12 Speed Trim Reference
8 P42.14 Torque Reference
9 P42.16 Torque Limits
10 P42.18 Torque Limits
11 P42.20 Temperature Compensation Scale
12 P42.22 Flux Limit
13 P42.24 Current Limit
14 P42.26 Torque/Magnet. Current
15 P42.28 Torque/Magnet. Current
16 P42.30 Position Reference
17 P42.32 Position Reference
