Converteam MVS3007 - Page 95

ALSPA PROFIBUS Field Bus Coupler Appendix B. Configuration Tables
(09/06) Technical Manual Page B5
18 P42.34 Tacho Feedback
Table B-1 PROFIBUS control words
No. Param. Mapped
From
Fallback
Value
Description
Example
1 P75.08 75.22 0
1 P75.08
2 P75.00
Table B-2 Control Word 1, P75.08
Bit Control Flag
Number
Fallback
Value
Description
Example
0 5.100 0 Bit 0 mapped to Stop flag
0 5.100
1 5.101
2 5.102
3 5.103
4 5.104
5 5.105
6 5.106
7 5.107
8 5.108
9 5.109
10 5.110
11 5.111
12 5.112
13 5.113
14 5.114
15 5.115
Table B-3 PROFIBUS References
No. Param. Destination
Parameter
Fallback
Value
Description
Example
1 P75.23 75.12 0 Speed Reference
1 P75.23
2 P75.24
3 P75.25
4 P75.26
5 P75.27
