Form 6 Microprocessor-Based Pole-mount Recloser Control Installation and Operation Instructions
26
TB1
SS1
1
2
35
7
91113151719
4
68
10
12
14
16 18
CI1
CI2 CI3
SS1 CO1
CO2 CO3
CO4
CI1 CI2 CI3
CO1
CO2
CO3
CO4
Remote Trip and Lockout
Supervisory Trip and Lockout
Supervisory Close
Control
Lockout
Status
(Not
Lockout)*
Recloser
Status
(Recloser
Open)*
A
B
Hotline
Tag
Status
(Hotline
Tag Off)*
Control
OK
Status
(Control
Not OK)*
Ground Trip
Blocked
Status
(GRD TRIP
Normal)*
Customer Wiring
Remote/Supervisory Common
Customer-Supplied
Voltage Inputs**
**Whetting voltage is also available from
the Form 6 Recloser Control on
Terminal Block TB9. Refer to Figure 22.
Note: Contact output relays revert to
de-energized positions as shown
upon downloading new schemes
or Workbench files.
*Relay Contacts shown
for Indicated Status
Figure 20.
Form 6 pole-mount recloser control standard default supervisory input control and output status contacts.
IMPORTANT
Shielding and Surge Protection of
Supervisory Cables
All supervisory operation and control monitor leads must
be protected within shielded cables. Refer to Figure
22.
NOTICE: External leads must be shielded and the shield
must be grounded at both ends. Terminate each lead
with a 320VAC, 150 Joules metal oxide varistor (MOV),
or equivalent, at the remote end. Attach MOV’s between
the leads and ground. Failure to properly shield and
protect leads can result in equipment damage and/or
unintentional operation.
