Cooper Power Systems Form 6 Series User Manual

Form 6 Microprocessor-Based Pole Mount Recloser Control Installation and Operation Instructions
36
Figure 30.
240 VAC low-voltage closing with 3-pin input and 2-pin output receptacle (KME6-1775-E).
Note: Terminal Block
positions TB7-3
and TB7-4 are fac-
tory-jumpered
together.
Terminal Block
positions TB7-5
and TB7-6 are fac-
tory-jumpered
together.
WARNING: Hazardous voltage. Before applying
power to the control, confirm that male pins of
the input power receptacle are electrically insulated to
prevent unintentional contact with 120V AC voltage.
Failure to do so may result in severe personal injury or
death. T372.0
DANGER: Hazardous voltage. Do not
connect potential transformer low-voltage
secondaries to the control through cables or
other wiring until the unit is installed in the field.
Transformer high-voltage primary windings will
become live when 120V AC is applied to the con-
trol from an alternate source if the transformer
secondary is connected. Failure to comply may
result in severe personal injury or death. T371.1
1
65
43
2
Power Connections
TB7
120/240
NEU
NEU
120 (L1)
1
4
3
2
7
1211
109
8
TB8
Voltage Sensing Connections
Source
Load
V (1-2) V(3-4)
V(5-6)
V1
V2
V3
5 6
BØ
White
120
(L2)
Factory Wiring for Wye Connection
Black
Low Voltage
Closing Receptacle
R3
A B
240 VAC
Black White
R2
A B C
240 VAC Incoming Power
Black Red
Input
Receptacle
White
1
2
TB10
120/240 VAC
Power Supply
1 2 4
Black White
Connections
1
2
Red
1
2
Black
120 VAC 120 VAC
