Automated Beverage System
© 1999 The Coca-Cola Company, Cornelius and
McDonald’s Corporation. All Rights Reserved.
15
Cup To Dispensing Nozzle
Sensors check for cup too high and a cup in
position A. If these sensors are clear, the con-
veyor moves the cup to the beverage fill point.
The valve opens to dispense the desired syrup
and water in the desired portions into the cup.
Beverage Dispensed
The computer sends the drink portion of the
order to the A.B.S. where the information is
interpreted and the drink is dispensed.
If the drink requires a top-off, the initial por-
tion will be dispensed. After a delay, the bal-
ance of the drink will be dispensed.
Automatic Operation
