Alarm & Warning Messages
When an alarm occurs, press the Silence/Alarm button to silence the alarm. Read the display
to determine the problem so that the appropriate corrective action can be taken.
LEFT and RIGHT arrow are used to scroll the alarm list and the number of unresolved warn-
ings and alarms are displayed with direction cues to scroll.
Listed below are all of the Alarm and Warning messages that may appear on the display
screen.
Message Explanation Corrective Action
(X) CUP OUT AT STATION (Y) The cup tube for size (X) is empty at
station (Y).
Refill the empty cup tube with
the correct cup size and then
press ENTER to continue dis-
pensing.
CLEAR SYRUP SOLD OUT The clear syrup (Sprite) is sold out
(empty B.I.B.).
Sensor must be installed and con-
nected to the A.B.S. system for this
warning to occur.
Connect a new syrup supply and
the A.B.S. unit will continue.
If the ENTER button is pressed
before the syrup supply is
replenished, automatic opera-
tion will resume but only the cup
and ice will be dispensed for this
flavor.
LOW ICE – REFILL SOON Ice level in the ice bin is too low. Refill the ice bin with ice. Press
ENTER.
CLEAR CUP JAM Cup(s) jammed in the conveyor at
the cup extraction position and the
conveyor and turret are unable to
operate.
Remove all cups from the con-
veyor cup holders at the Extract
Position before pressing the
ENTER button. Another cup will
be extracted and dispensing will
continue.
NO CUP EXTRACTED The gripper did not or could not
extract a cup from the cup tube.
Check cup supply at the extract
station and make sure the cups
are not stuck. Make sure the
gripper pads are not damaged.
TURRET STALLED Cup(s) jammed in the conveyor at
the cup extraction position and the
conveyor and turret are unable to
operate.
Remove all cups from the con-
veyor cup holders at the Extract
Position before pressing the
ENTER button. Another cup will
be extracted and dispensing will
continue.
CONVEYOR STALLED Cup(s) jammed in the conveyor at
the cup extraction position and the
conveyor and turret are unable to
operate
Remove all cups from the con-
veyor cup holders at the Extract
Position before pressing the
ENTER button. Another cup will
be extracted and dispensing will
continue.
AIR OR CO
2
LOW OR OUT CO
2
supply is low or empty or air
compressor not operating.
Change CO
2
cylinder pr have
bulk tank refilled. Check cause
not operating and repair.
