Auto-Agitate
Ice from the bin is used for the coldplate.
If the A.B.S. unit is idle for a period (pro-
grammed during setup), the agitator will agi-
tate for a preset period to maintain ice on the
coldplate.
The ice bin has a sensor that detects a low ice
condition and displays a warning.
Ice Chute
The ice chute directs the ice into the cup. It
can be removed for cleaning or replacement.
Access to the ice chute is obtained by remov-
ing the cup lid rack.
A.B.S. unit Major Subsystems Operation —
Ice Dispenser
