Cornelius A.B.S. Unit - Assembled Unit Diagram; Product View

Automated Beverage System
© 1999-2001 The Coca-Cola Company, Cornelius
and McDonald’s Corporation. All Rights Reserved.
Illustrated Parts List
5
Automated Beverage System —
Ref CCUSA MFG.
Number Number Number Description
PRINTED ON RECYCLED PAPER
10% Post-Consumer Content
40% Pre-Consumer Content
1.................... ................560000260.....Ventilation Grill
2.................... ................ 560000245.....Access Hole Cover
3.................... ................560000291.....Air Filter
4.................... ................ 560000289.....Front Panel (Built before Serial No. 56A0019AB102)
...................... ................560002774.....Front Panel (Serial No. 56A0019AB102 and after)
Assembled Unit Diagram
A.B.S. Unit Access
1
2
3
4
TURRET
FLAVOR DISPLAY
CUP GRABBER
CONTROL PANEL
ON/OFF SWITCH
OPTIONAL PRECHILLER
