Cornelius CCM0330 - Page 60

Refrigeration System
Page E14
CCU0150A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 167 150 59 35 83 93 125 153 43 24 18'11" 1'56" 20'07"
70/50 228 205 72 41 104 118 145 177 55 29 23'05" 1'10" 24'15"
90/70 305 262 89 43 126 150 165 201 68 35 37'32" 0'45" 38'17"
108/98 400 325 107 44 126 183 183 229 88 36 84'18" 0'51" 85'09"
CCU0150W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 250 250 65 42 98 109 157 195 53 34 21'33" 1'01" 22'34"
70/50 250 250 69 42 103 118 167 203 58 35 24'11" 1'06" 25'17"
90/70 250 250 80 41 108 130 169 207 66 34 29'19" 1'01" 30'20
110/100 288 254 95 42 112 137 178 217 82 37 39'52" 1'01" 40'53"
CCU0220A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 191 162 61 31 82 85 110 145 41 20 12'38" 2'04" 14'42"
70/50 260 216 71 34 102 112 125 170 55 22 17'31" 1'12" 18'43"
90/70 327 276 81 39 118 140 144 190 70 28 27'53" 0'55" 28'48"
109/95 428 350 94 39 154 181 174 231 87 28 53'07" 0'49" 53'56"
CCU0220W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv Start End Start End Freeze Harvest Complete
50/40 250 250 59 32 82 97 120 171 44 18 14'29" 1'36" 16'05"
70/50 250 250 63 37 98 104 127 176 51 22 15'29" 1'11" 16'40"
90/70 250 250 70 37 107 117 135 182 62 25 18'32" 1'10" 19'42"
110/100 290 266 77 39 118 132 145 196 77 29 25'41" 0'46" 26'27"
