Cornelius CCM0330 - Page 61

Refrigeration System
Page E15
CCU0220A (230/60/1)
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 183 164 57 38 80 83 109 138 44 26 10'54" 1'40" 12'34"
70/50 265 225 69 35 102 111 127 171 58 31 19'50" 1'16" 21'06"
90/70 330 275 81 36 117 138 141 189 71 35 26'32" 1'04" 27'36"
110/100 435 363 92 43 145 169 169 223 88 47 53'17" 0'39" 53'56"
CCM0330A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40
193-263
cycling
75 28 122 128 114 158 51 37 9'14" 0'49" 10'03"
70/50 257 196 65 28 100 108 118 159 56 35 10'46" 0'59" 11'45"
90/70 296 241 93 31 146 146 138 184 76 54 15'09" 0'41" 15'50"
110/100 381 299 107 33 150 167 166 209 89 57 28'31" 0'44" 29'15"
CCM0330W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
70/50 250 250 60 25 94 98 118 157 54 32 11'22" 1'05" 12'27"
90/70 250 250 67 25 112 117 127 169 61 37 13'13" 0'51" 14'04"
110/100 298 268 86 26 153 160 139 186 82 51 18'31" 0'41" 19'12"
CCM0322A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
70/50 232 187 62 22 101 110 111 156 53 37 11'53" 1'01" 12'54"
90/70 312 247 81 27 136 144 132 184 72 50 16'31" 0'27" 16'58"
110/100 412 315 107 33 177 188 153 214 94 65 26'21" 0'41" 27'02"
