Refrigeration System
Page E16
CCM0322W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
70/50 252 244 63 25 94 99 121 165 44 30 10'57" 0'55" 11'53"
90/70 254 246 75 28 108 115 134 178 61 40 12'43" 0'50" 13'33"
110/100 325 268 101 30 151 173 130 201 83 57 17"51" 0'40" 18'31"
CCM0430A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40
198-260
cycling
63 38 100 108 105 157 53 38 10'23" 1'03" 11'26"
70/50 263 200 67 37 99 111 105 157 54 37 12'14" 1'00" 13'14"
90/70 292 251 88 39 120 135 114 181 70 56 20'20" 0'48" 21'08"
110/100 383 302 110 41 140 170 126 206 90 62 44'06" 0'34" 44'40"
CCM0430W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv Start End Start End Freeze Harvest Complete
50/40 250 250 63 38 91 98 98 157 45 30 10'47" 1'10" 11'57"
70/50 250 250 73 41 100 106 105 170 57 41 13'18" 0'58" 14'16"
90/70 255 250 83 39 113 123 108 179 68 43 17'16" 0'55" 18'11"
110/100 275 251 96 38 140 154 114 192 83 45 24'42" 0'51" 25'33"
CCM0530A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40
198-265
cycling
57 33 100 110 115 159 50 37 8'03" 0'52" 8'55"
70/50 265 217 59 31 92 95 127 179 55 41 10'42" 1'08" 11'50"
90/70 325 280 70 34 118 126 141 198 70 49 14'54" 0'45" 15'39"
110/100 435 350 84 36 150 163 165 225 88 60 24'46" 0'49" 25'35"
