Cornelius CCM0330 - Page 63

Refrigeration System
Page E17
CCM0530W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 250 250 56 31 85 89 116 171 46 26 9'55" 1'19" 11'14"
70/50 250 250 61 31 90 95 121 177 52 28 11'17" 1'10" 12'27"
90/70 250 250 69 33 105 113 127 187 63 35 13'24" 0'57" 14'21"
110/100 314 277 82 33 145 152 136 212 86 43 20'26" 0'49" 21'15"
CCM0530R
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
-20/40 200 207 52 37 66 64 130 167 38 30 9'52" 2'07" 11'59"
70/50 240 240 52 33 65 65 146 180 53 28 11'52" 1'01" 12'53"
90/70 271 245 56 35 66 68 169 193 56 26 15'03" 0'51" 15'54"
110/100 390 340 56 33 66 68 182 233 60 46 29'59" 0'56" 30'55"
CCM0522A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 230 248 55 39 80 87 95 149 42 34 9'51" 1'25" 11'16"
70/50 262 254 67 39 95 103 102 154 54 39 12'28" 1'07" 13'35"
90/70 316 273 84 42 122 134 116 183 72 52 19'12" 0'41" 19'53"
110/100 403 335 105 42 140 168 130 207 95 62 33'26" 0'35" 34'01"
CCM0522W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv Start End Start End Freeze Harvest Complete
50/40 261 248 60 30 83 86 100 164 47 26 10'06" 1'23" 11'29"
70/50 252 247 59 30 92 95 121 177 52 28 11'14" 1'00" 12'14"
90/70 254 249 68 32 104 112 127 187 64 36 13'24" 0'55" 14'19"
120/100 314 277 82 33 145 152 135 212 86 42 20'27" 0'47" 21'14"
