Cornelius CCM0330 - Page 64

Refrigeration System
Page E18
CCM0630A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40
198-270
cycling
51 29 86 95 108 157 51 36 7'51" 0'48" 8'39"
70/50 270 205 51 27 80 86 107 159 51 37 9'48" 1'15" 11'03"
90/70 316 260 62 32 103 113 122 182 66 48 13'40" 0'42" 13'40"
110/100 415 319 80 34 132 143 132 206 88 59 26'37" 0'42" 27'19"
CCM0630W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 250 250 48 27 67 70 102 155 44 21 8'17" 2'19" 10'36"
70/50 250 250 50 27 66 72 104 162 44 23 8'40" 1'58" 10'38"
90/70 250 250 54 28 78 85 110 169 53 28 11'33" 1'28" 13'01"
110/100 360 301 74 30 117 135 133 206 81 40 23'43" 0'50" 24'33"
CCM0630R
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
-20/40 238 238 46 33 93 86 107 159 54 44 7'28" 0'46" 8'14"
70/50 280 270 53 33 108 111 118 181 65 50 11'12" 0'42" 11'54"
90/70 293 275 58 33 118 124 120 189 74 52 13'55" 0'43" 14'38"
120/100 410 332 82 32 161 176 140 221 96 62 30'27" 0'40" 31'07"
CCM0830A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 203 176 55 31 75 79 96 143 43 35 7'09" 2'12" 9'21"
70/50 245 222 61 35 90 96 103 160 53 41 9'21" 1'06" 10'27"
90/70 315 277 65 37 108 118 115 185 71 52 14'19" 1'00" 15'19"
110/100 392 331 76 39 125 144 120 210 89 62 25'11" 0'50" 26'01"
