Cornelius CCM0330 - Page 65

Refrigeration System
Page E19
CCM0830W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
70/50 250 250 59 34 72 76 103 159 43 27 8'36" 2'01" 10'37"
90/70 250 250 61 34 79 88 105 165 49 32 10'52" 1'10" 12'02"
110/100 321 293 78 35 108 121 116 193 65 45 18'32" 0'55" 19'27"
CCM0830R
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
-20/40 240 240 61 29 100 108 100 160 51 41 9'46" 1'06" 10'52"
70/50 285 265 68 36 115 122 108 170 60 45 9'31" 1'00" 10'31"
90/70 294 272 72 35 118 125 111 177 63 46 11'12" 0'56" 12'08"
110/100 401 326 90 33 136 160 120 216 79 57 22'34" 0'50" 23'24"
CCM1030A
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F
Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv
Start End Start End Freeze Harvest Complete
50/40 186 176 50 33 70 68 100 132 41 35 4'48" 1'56" 6'44"
70/50 233 210 56 30 78 82 104 152 46 32 8'00" 1'26" 9'26"
90/70 307 267 68 33 98 104 115 177 62 34 12"03" 1'01" 13'04"
110/100 374 325 68 33 115 130 127 205 84 53 23'25" 0'36" 24'01"
CCM1030W
Ambients Refrigeration Pressures PSIG
Compressor Temps
°F Cycle Times
°F
Discharge Suction Discharge Suction Minutes' Seconds"
Air/Water Start End Start Freeze End Freeze
Start
Harv
End
Harv Start End Start End Freeze Harvest Complete
70/50 249 244 58 27 69 66 108 163 44 23 8'34" 2'32" 11'06"
90/70 256 250 59 29 70 77 110 168 48 30 9'31" 1'39" 11'10"
110/100 320 289 75 28 98 110 117 192 68 42 15'55" 1'06" 17'01"
