IDC Pro 255 Service Manual
Publication Number: 621058649SER - 8 - © 2016, Cornelius Inc.
MULTI-FLAVOR VALVE CONFIGURATION
Disconnect power to the unit before accessing the MFV valve.
Table 2.
Step Action
1 Back-block layout behind each valve bank.
Figure 4.
2
MFV Valve Module placed on the back-block.
Figure 5.
3
Press the top snap (Dovetail) of black-block
towards down as indicated in Figure 6.
Figure 6.
