Cornelius IDC PRO 255 - Intake Fan Removal

IDC Pro 255 Service Manual
© 2016, Cornelius Inc. - 13 - Publication Number: 621058649SER
Intake Fan Removal
Table 6.
4 Reverse process for re-installation.
Step Action
1
Remove the intake fan cover by unscrewing the
four screws, pull the cover up front and disconnect
the harness.
Figure 19.
2
Loosen the nuts from all the four corners and pull it
out.
3 Reverse process for re-installation
Step Action
Intake Fan
