DISASSEMBLY OF AN MFV VALVE MODULE
Table 3.
4
Each round shutoff (Spindle) needs to be pressed
towards down as shown as in Figure 7 to allow fluid
to flow past the back-block into the valves.
Figure 7
Step Action
1
Once the valve module is removed, pull the locking
clip towards up and remove.
Figure 8.
Step Action
