REASSEMBLY Of MFV VALVE
Table 4.
2
Pull up and rotate valve upwards of bracket to
remove from the module.
NOTE: Check for all O-rings on bottom of
valves.
Figure 9.
3
Rotate solenoid counterclockwise and remove to
service the solenoid and plunger.
NOTE: Solenoid should read 9.1ohms
Figure 10.
Step Action
1 Place valve into the valve carrier.
Figure 11.
Step Action
