IDC Pro 255 Service Manual
Publication Number: 621058649SER - 36 - © 2016, Cornelius Inc.
EDITING THE MEDIA PLAYLIST
The unit is capable of changing the display video on a preprogrammed schedule. This allows the user to set a specific
time and duration for playing a specific media for breakfast, lunch, dinner or any special media required.
To set the media playlist schedule, perform the procedure in Table 24.
7 The second Update Software screen is displayed.
Figure 74.
8
Select the software version to be installed by selecting from the list on the left side of the screen. If the list on the
left side of the screen is empty, press the Scan button. This reads the software updates contained on the USB
stick. When the proper version is highlighted, press the Install Software button on the right side of the screen.
9
When the update is complete, press the Back button to revert to the previous screen, then press the Restart/
Refresh button to restart the unit.
10 Unplug the USB stick from the connector and reinstall the ADA cable.
11 Close the display panel.
Table 24.
Step Action
1 First, enter the Service Screen at either manager or technician level permissions.
2
Display the keypad screen by tapping each corner of the
video screen Starting in the upper right corner (1) and con-
tinuing to tap each corner in a Counter clockwise direction
in a sequence of 1,2,3 and 4 as shown in Figure 75.
NOTE: As each corner is touched, a small
confirmation rectangle may momentarily
appear to confirm the touch.
Figure 75.
Table 23.
Step Action
To Next Page
