IDC Pro 255 Service Manual
Publication Number: 621058649SER - 16 - © 2016, Cornelius Inc.
NOZZLE DIFFUSER REMOVAL
Diffuser cleaning or sanitizing is recommended twice weekly.
Table 9.
Step Action
1
Turn nozzle counterclockwise (left) pull
down, the diffuser will stay in position (it is
keyed only fits one way).
Figure 26.
2
Pull diffuser down. Clean with warm soapy
water then sanitize and reinstall.
NOTE: Do not soak for more than 2 minute.
Seal may warp
Figure 27.
3 Repeat removal process for each side.
Figure 28.
4 Reverse process for re-installation
