IDC Pro 255 Service Manual
Publication Number: 621058649SER - 24 - © 2016, Cornelius Inc.
5
Press the Brand or Flavor icon that is to be
remapped.
Figure 43.
6
The Brand Selection screen opens as shown in
Figure 44 and you can select the brand to be
mapped to the valve location.
Figure 44.
7 Repeat Steps 4 & 6 for each location desired.
8
When all the flavors or brands on the right are mapped, press the left button and repeat Steps 4 and 6 for the left
side or, if the setup will be identical on the LH and RH side, press the copy to other side button and confirm when
prompted.
9 When all the flavors or brands are mapped as desired, press the Save button to save the settings.
Table 16.
Step Action
